Two students measure the same damped pendulum. One records amplitudes; the other records amplitudes, processes them with logarithms, draws one straight line and reads off a decay constant and an initial amplitude. The second student has turned raw readings into a result. Unit 6 tests exactly that step.
WPH16 Practical Skills in Physics II is a written paper about the experiments you met while studying Units 4 and 5: gas laws, capacitors, damped oscillations, radioactive decay, light intensity. It lasts 80 minutes and has 50 marks. All questions are compulsory, and at least 20 marks use Level-2 mathematics. A written guide supports real laboratory work; it does not replace carrying out experiments yourself.
The four skill sheets follow the paper's own flow: plan the investigation, carry it out and judge the measurements, then process the data with uncertainties and graphs.
6.1
A2探究规划
教学大纲
Pearson Edexcel IAL Physics Issue 3 (July 2021), printed pp.38–40 and Appendix 10 pp.75–81. These are local teaching subdivisions, not numbered official specification statements.
Planning A2 investigations (specification section 6.3 with the log-graph emphasis of section 6.1): identify apparatus with range and resolution; discuss calibration and zero checks; describe measuring techniques; identify and control other variables; judge repeats; deal with health and safety; explain how data will be used. At A2 the processing route is chosen before the method is written: test a power law with a log/log graph or a linearising plot, extrapolate a straight line to a physical limit (for example absolute zero), and build circuits that measure what the investigation needs (voltmeter placement, series ammeter, means of varying current, two-position switching). Justify improvements such as data loggers through their effect on resolution, parallax or simultaneity of readings.
来源：Cambridge International 教学大纲
A valid measurement 有效测量 still means measuring what you intend to measure. At A2 the plan has one extra demand: decide how the data will be processed before writing the method. The graph you intend to draw decides how many readings you need and where you take them.
Choose the graph before the method
Suppose you must test a predicted relationship. Work backwards:
Write the model, for example $P = kX^4$ or $A = A_0\mathrm{e}^{-\lambda n}$.
Rearrange it into the straight-line form $y = mx + c$. This step is linearisation 线性化: choose a plot such as $P$ against $X^4$, $\ln A$ against $n$, or $\lg P$ against $\lg X$.
State what the graph proves: a straight line through the origin for $P$ against $X^4$, or gradient 斜率 $4$ on the log graph 对数图像 of $\lg P$ against $\lg X$.
Then choose the readings: at least five well-spread settings of the quantity you change.
A plan without its graph is an unfinished plan. The paper's six-mark "devise a method" questions expect the graph to appear in the answer.
Worked planning example: absolute zero from a gas flask
A flask of fixed air volume carries a pressure gauge and a thermometer. Predict how to estimate absolute zero.
Known aim: the pressure of a fixed mass of gas falls linearly with temperature and reaches zero at absolute zero. Why this route: the zero-pressure point cannot be reached in water baths, but a straight line can be extended to it.
Use a beaker of water with ice for $0\ ^\circ\mathrm{C}$ and a hot plate (or Bunsen burner) to raise the temperature to boiling. Stir so the water shares one temperature.
Place the thermometer close to the flask, on the side away from the heater, and read the scale perpendicular to it.
Record paired pressure and temperature readings at a minimum of five temperatures, spaced no more than about $20\ ^\circ\mathrm{C}$ apart. These are new settings, not repeats of one setting.
Plot pressure against temperature in $^\circ$C, draw the best-fit line 最佳拟合线 and extrapolate 外推 it to $p = 0$. The intercept 截距 on the temperature axis estimates $-273\ ^\circ$C.
Extrapolation extends a straight line beyond the measured range; the measured points themselves stay between ice and boiling water.
The extrapolated answer depends on the fitted line, so scatter matters more here than in a single reading. That is the price of a point you cannot measure directly.
Worked planning example: testing a power law
A light sensor a fixed distance from a filament bulb reads $X$; the electrical power is predicted to follow $P = kX^4$.
Control what else changes $X$: keep the bulb-sensor distance and alignment fixed, and work in a darkened space so background light does not add to the reading.
Measure the current $I$ and potential difference $V$ at each setting, and calculate $P = IV$.
Take at least five settings by changing the current, then choose one of two graphs:
$$\lg P = \lg k + 4\lg X \qquad \text{or} \qquad P = k\,(X^4)$$
A graph of $\lg P$ against $\lg X$ should be straight with gradient $4$. A graph of $P$ against $X^4$ should be straight through the origin. Either answers the question; name the expected gradient or origin when you claim the test.
A power law becomes a straight line on log/log axes; the gradient is the power.
The specification's own example is a gas: plot an appropriate log/log graph of pressure against volume for a fixed mass at constant temperature. Log graphs are not only for exponential decay.
Circuits that measure what the investigation needs
An investigation of a component needs both meters in the right places:
an ammeter 电流表 in series with the component, so the same current flows through it;
a voltmeter 电压表 in parallel with the component under test only, so it reads that component's potential difference;
a way of changing the current: a variable resistor or potentiometer, in series with a fixed supply.
If the voltmeter straddles two components, the reading no longer belongs to the thing you are investigating. When a two-position switch moves a charged capacitor to a new circuit, draw the voltmeter across the one capacitor the question names, and connect the second capacitor in parallel with it.
Electrolytic capacitors add their own safety rules: connect with the correct polarity, keep the supply below the working voltage, and discharge the capacitor before handling it.
Data loggers and safety, with reasons
A data logger 数据采集器 with probes records pairs of readings at the same moment, removes parallax 视差 from scale reading, and its probes usually have a better resolution 分辨率 than a liquid-in-glass thermometer. Say which of these changes improves the measurement; "more accurate" alone names no mechanism.
Safety answers follow the same rule: name the hazard and the action. Hot water and immersion heaters burn — move glass with tongs or heat-proof gloves, and clamp the heater so its leads cannot topple the beaker. Switch off before removing anything electrical.
Pearson Edexcel IAL Physics Issue 3 (July 2021), printed pp.38–40 and Appendix 10 pp.75–81. These are local teaching subdivisions, not numbered official specification statements.
Implementation and measurement critique (specification section 6.4): comment on improvements from additional apparatus (set squares, timing markers); judge the number and range of readings; correct significant figures and units in results tables; identify inconsistent readings from tables and graphs; choose recording resolution matched to what can actually be judged (for example amplitude to the nearest 5 mm); apply timing techniques for oscillations (multiple periods, marker at the centre of the oscillation, starting after several oscillations); apply caliper and micrometer technique (different orientations with a mean, zero-error correction, ratchet use); complete and criticise circuits and plotted graphs; state component-specific safety such as electrolytic-capacitor polarity, working voltage and discharge.
来源：Cambridge International 教学大纲
Record what you can actually judge
A damped pendulum swings past a rule, and its turning points move quickly. Judging the amplitude to the nearest $1\ \text{mm}$ claims a precision the eye cannot deliver, especially viewing the scale at an angle or with the bob far from the rule. Recording to the nearest $5\ \text{mm}$ matches the recording to what can honestly be judged.
This is a two-way skill: criticise a recording resolution that is too fine, and justify a coarse one with the reason it is appropriate.
Timing oscillations
Measure the time for many oscillations, then divide. The reaction-time uncertainty is nearly the same whether you time one swing or ten, so a larger measured time gives a smaller percentage uncertainty in the period.
Two techniques earn marks on their own:
put a timing marker 计时标记 at the centre of the oscillation and time passes through it, because the mass moves fastest there and the moment of passing is clearest;
start the timer only after several oscillations, when the motion has settled, and use a small initial displacement.
For the period itself, record repeats of the total time, take the mean, and only then divide by the number of swings.
Length instruments at A2
The Unit 3 techniques still earn the marks, now with reasons attached:
measure a spring or cylinder diameter with calipers at several orientations 方位 around the coil or cross-section and average, because a real object is not perfectly round (this attacks random variation 随机变化);
check the zero reading with the jaws closed and subtract a zero error, because it shifts every reading the same way (this attacks a systematic error 系统误差);
use the micrometer ratchet so the jaws tighten the same amount each time.
Justifying an instrument is quantitative: a micrometer resolves $0.01\ \text{mm}$, so a single $1.21\ \text{mm}$ slide has an uncertainty of $0.005\ \text{mm}$. Its percentage uncertainty 百分比不确定度 is:
A small percentage uncertainty is the justification; "it is accurate" is not.
Criticising tables and graphs
For a table of results, check:
significant figures 有效数字: raw readings use the same decimal places as the instrument's resolution; processed values for plotting are commonly $3$ significant figures. A column mixing $5.1$ with $5.143$ has a fault to name.
units: every column heading carries its unit, once, in the heading.
values that stand outside the pattern of the others, judged against the graph as well as the table.
For a plotted graph, the examiner's checklist is short:
enough data points, spread over more than half of each axis, on scales that are not awkward (multiples of $3$ or $7$ are hard to read);
points plotted to within $1\ \text{mm}$ (half a small square);
a thin, continuous best-fit line that balances the scatter;
whether the points actually support a straight line at all.
Criticising a graph is not listing everything you know. Point at the actual defect: five points crowded into a quarter of the grid, or a gentle curve drawn as a line.
Pearson Edexcel IAL Physics Issue 3 (July 2021), printed pp.38–40 and Appendix 10 pp.75–81. These are local teaching subdivisions, not numbered official specification statements.
Compounded uncertainties and justified conclusions (specification section 6.5 uncertainty bullets, Appendix 10): estimate single-reading uncertainty as half the instrument resolution and repeated-reading uncertainty as half the range (or the reading furthest from the mean); express percentage uncertainties to one or two significant figures. Compound percentage uncertainties correctly: multiply by the power for a quantity raised to a power, add percentage uncertainties for products and quotients, add absolute uncertainties for sums and differences. Use a final uncertainty as an interval and compare a known or data-book value with the interval, or compare percentage difference with percentage uncertainty; state what the comparison supports without over-claiming uniqueness.
来源：Cambridge International 教学大纲
Unit 6 expects compounded uncertainties 复合不确定度, which Unit 3 did not. The rules come from the specification's Appendix 10.
The building blocks
A single reading has an uncertainty of half the instrument's resolution. Repeated readings have an uncertainty of half the range (the reading furthest from the mean is an accepted alternative). A percentage uncertainty is:
Quote percentage uncertainties to one or two significant figures. Halving or doubling a measured quantity leaves its percentage uncertainty unchanged, which is why percentages, not absolute values, are the working currency.
The three compounding rules
A power multiplies the percentage uncertainty. If $A = \pi r^2$ and $r$ has $0.6\%$ uncertainty, then $A$ has $2\times0.6\% = 1.2\%$. A diameter and its radius share the same percentage uncertainty.
Products and quotients add percentage uncertainties. Density $\rho = m/l^3$ from $m$ with $0.1\%$ and $l$ with $2.1\%$ gives $3\times2.1\%+0.1\% = 6.4\%$.
Sums and differences add absolute uncertainties. Subtracting two heights measured to $\pm0.5\ \text{mm}$ each gives $\Delta h = \pm1\ \text{mm}$, even though the heights themselves are several hundred millimetres.
The third rule is why differences of similar measurements carry large percentage uncertainties, and it combines with the first two: the percentage uncertainty of $D^2/(2d^2)$ is $2\times\%U(D) + 2\times\%U(d)$.
Worked example: the ramp measurement of g
A sphere rolls a distance $s$ down a ramp of height difference $\Delta h$ in time $t$, where:
$$t^2 = \frac{14s^2}{5g\,\Delta h} \qquad\Rightarrow\qquad g = \frac{14s^2}{5t^2\Delta h}$$
Known: $s = 90.0\ \text{cm}\pm0.1\ \text{cm}$, $\Delta h = 21\ \text{mm}\pm1\ \text{mm}$, $t = 3.36\ \text{s}\pm0.03\ \text{s}$. Why these rules: $s$ and $t$ are squared (powers), and the quantities are multiplied and divided.
Both routes end in a sentence that states what the evidence supports. A value of $\nu = 0.276\pm6\%$ spans $0.259$ to $0.293$; a data-book $0.265$ for steel falls inside, so the spring could be steel. That is the honest strength of the claim — the interval does not prove it is steel, only that steel is not excluded.
Pearson Edexcel IAL Physics Issue 3 (July 2021), printed pp.38–40 and Appendix 10 pp.75–81. These are local teaching subdivisions, not numbered official specification statements.
Log graphs and linearisation (specification section 6.5 graph bullets with section 6.1): linearise an exponential relation with natural logs (ln y = ln y0 − kt form), including units and signs; linearise a power law y = kx^n with lg y against lg x (gradient n, intercept lg k) or by plotting against x^n; process data to a consistent three decimal places for plotting; label log axes with the exact quantity logged; plot with appropriate scales, draw a best-fit line and take the gradient from a large triangle; convert a gradient or intercept back into physical quantities (for example e to the power of an intercept); use a fitted relation to predict a new condition (whole-number slide counts, percentage reductions); judge the validity of extrapolation from scatter, possible systematic error or absence of data near the intercept.
来源：Cambridge International 教学大纲
Straighten an exponential with ln
A damped pendulum's amplitude follows $A = A_0\mathrm{e}^{-\lambda n}$, where $n$ counts oscillations. Take the natural logarithm of both sides:
$$\ln A = \ln A_0 - \lambda n$$
Compare this with $y = c + mx$: a graph of $\ln A$ against $n$ is straight, with gradient $-\lambda$ and intercept $\ln A_0$. The minus sign is part of the physics — amplitude decays, so the line slopes down.
Worked example. The line's intercept is $2.295$ and its gradient is $-0.0355$.
Known: intercept $=\ln A_0$, gradient $=-\lambda$. Why: $A$ was measured in centimetres, so $\ln(A/\text{cm})$ was plotted.
$\lambda$ has no unit because $n$ is a count. Had $n$ been time in seconds, $\lambda$ would carry $\text{s}^{-1}$.
Processing discipline: compute $\ln$ of every value to a consistent $3$ decimal places, label the axis with the exact quantity logged — $\ln(A/\text{cm})$, not "$\ln A$" with a unit bolted on — and take the gradient from a large triangle 大三角形 covering more than half the drawn line, using points on the line rather than data points off it.
When the intercept is an extrapolation
$A_0$ sits at $n = 0$, where there is no data if the first reading was taken at $n = 5$. The intercept is then only as good as the fitted line:
large scatter leaves the best-fit line uncertain, moving the intercept;
a systematic error in amplitude shifts the whole line;
the pendulum's first swings may not follow the model (a large starting angle stretches the period and distorts early amplitudes).
"Extrapolating beyond the data assumes the model still holds" is the sentence that earns the mark. Say which of these applies to the experiment in front of you.
Use the fitted line to predict
A fitted relation answers questions the raw table cannot. If $\ln V = \ln A - Bw$ for light passing through glass, and the line gives $B = 0.0104\ \text{mm}^{-1}$, the thickness $w$ needed to dim a reading to $75\%$ follows without touching the apparatus again:
With slides of $1.22\ \text{mm}$ each, that is $27.7/1.22 = 22.7$, so $23$ slides — round up, because $22$ slides would not reach the required dimming. Prediction questions test the direction of the final rounding as much as the algebra.
Straighten a power law with lg
For $y = kx^n$, taking base-10 logarithms gives:
$$\lg y = \lg k + n\lg x$$
A graph of $\lg y$ against $\lg x$ is straight with gradient $n$ and intercept $\lg k$. Use it when no power of $x$ makes a convenient linear axis, and keep the base consistent: $\lg$ for the power-law plot, $\ln$ for the exponential one. Both operate on the number after the unit is divided out, so the axis label is $\lg(P/\text{W})$, never $\lg P$ with watts attached.
